Hardware

NECp462

Touch Type
Dispersive Signal Technology (DST) built by 3M
The touch position is determined by “bending waves” created by a finger. The touch screen is unaffected by surface contaminants such as dirt, dust and grime.

Monitor
LCD with LED backlight

Resolution
Full 1080P

Operation
Industrial-strength, premium-grade panel with additional thermal protection, internal temperature sensors which allow for 24/7 operation.

Slide-In PC
Open Pluggable Specification (OPS) port allows for a PC to be ported into the slot and running off the same power source.
Currently running at Hilton concierge

Power Consumption
155W

elo4201L

Touch Type: Optical
Touch is optical which is controlled by 4 cameras in the corners of the monitor. Infrared back lights are places in the camera’s field of view on the other side of the screen. A touch shows up as a shadow and the cameras can pinpoint exact location of the touch.

Monitor
LCD with LED backlight

Resolution
Full 1080P

Operation
Professional-grade hardware with strengthened touch screen glass to withstand public use. Design allows for 24/7 operation.

Slide-In PC
Open Pluggable Specification (OPS) port allows for a PC to be ported into the slot and running off the same power source.

Power Consumption
85W

elo22_2

Monitor
LCD with LED backlight. 22” Projective Capacitive ELO Multi-touch (Also available in wide viewing angle), Glass surface.

Resolution
Full 1080P

Operation
Product designed to run 24/7

Power Consumption
75 Watts total

Dimensions
12.5” x 20.5” x 3” (WxHxD)

PC
Intel i3/i5 NUC with 4GB memory, 60GB SSD and Win 7 Embedded.

Unit is fully enclosed in a polished metal frame that comes with a wall bracket and sits less than 4” from the wall which follows ADA requirements.

Touch Type Projective Capacitive is made up of a matrix of rows and columns of conductive material, layered on sheets of glass. When a conductive object (Finger) touches the screen a distortion of the electrostatic field is created which can pinpoint the location of the touch.

DFImk20

Touch Type
Projective Capacitive is made up of a matrix of rows and columns of conductive material, layered on sheets of glass. When a conductive object (Finger) touches the screen a distortion of the electrostatic field is created which can pinpoint the location of the touch.

Monitor
LCD with LED backlight

Resolution
1600 x 900

Operation
Product designed to run 24/7

Power Consumption
50 Watts total

Dimensions
12.9” x 23” x 2.6” (WxHxD)

PC
Intel i3/i5/i7 with up to 16GB memory, 60-128GB SSD, and Win 7 embedded

Fully enclosed frame with metal construction

ChargingStation

Monitor
19” Touch LCD

Power Consumption
150-200 Watts (standard outlet). With power saving features when not in use.

Dimensions
68” x 22” x 14” (H x L x W)

Audio
Dual speakers

Weight
170 Pounds

Warranty
1 year

Operating System
Windows 7

Operating temperatures
10 to 35 degrees Celsius

The charging station is designed to support almost all phones and standard tablets.

6 Secured lockers which are color coded with LEDs based upon vacant (Green), occupied (red), and open (white).

Guests can gain access to individual charging lockers via smart card technology or 4 digit pass code. Each unit will either come equipped with a card reader or pin pad for locker verification.
